CONNECT BAND
CONNECT BAND is the wall barrier sheath for substrates that provides double protection: it prevents rising damp in the timber and ensures excellent airtightness. Available in two versions, can be used with different wall thickness values.
CONNECT BAND, the sealing wall barrier that adapts to even the most uneven surfaces
Description
The CONNECT BAND waterproofing membrane adapts to the surface on which it is installed: the PU foam adhesive profiles compensate for possible unevenness in the substrate.
It is extremely thermostable and flexible even at low temperatures and is compatible with bitumen and all major building materials.
Documents
-
Technical data sheets
- Technical data sheets Croatian
- Technical data sheets Czech
- Technical data sheets English
- Technical data sheets French
- Technical data sheets German
- Technical data sheets Greek
- Technical data sheets Hungarian
- Technical data sheets Italian
- Technical data sheets Polish
- Technical data sheets Portuguese
- Technical data sheets Romanian
- Technical data sheets Russian
- Technical data sheets Slovene
- Technical data sheets Spanish
CONNECT BAND
| CODE | B
[mm]
|
s
[mm]
|
L
[m]
|
B
[in]
|
s
[mil]
|
L
[ft]
|
pcs. |
|---|---|---|---|---|---|---|---|
| CONNECT100 | 100 | 0.8 | 25 | 3.9 | 31 | 82 | 1 |
| CONNECT250 | 250 | 0.8 | 25 | 9.8 | 31 | 82 | 1 |
Technical Data
| Property | Standard | Tested Values | USC Conversion |
|---|---|---|---|
| Water vapour transmission (Sd) | EN 1931 | 55 m | 0.064 US perm |
| Water vapour resistance factor (μ) | - | ca. 79000 | - |
| Tensile strength | DIN 53504 | ≥ 6,5 N/mm² | ≥ 943 lbf/in² |
| Elongation | DIN 53504 | ≥ 300 % | - |
| Resistance to tearing | DIN 53504 | ≥ 25 kN/m | ≥ 143 lbf/in |
| Watertightness | - | compliant | - |
| Reaction to fire | EN 13501-1 | class E | - |
| Resistance to temperature | - | 30 / 100 °C | 86 / 212 °F |
| Application temperature | - | 5 / 35 °C | 41 / 95 °F |
| Storage temperature (1 ) | - | 1 / 25 °C | 34 / 77 °F |
| Resistance to UV and ozone | DIN 7864-1 | compliant | - |
| Resistance to penetration of air | EN 12114 | ≤ 0,1 m³/(h·m·daPaⁿ) | - |
| Thermal conductivity (λ) | - | 0,04 W/(m·K) | 0.02 BTU/(h·ft·°F) |
| French VOC classification | ISO 16000 | A+ | - |
| VOC emissions | EN 16516 | very low | - |
| Solvents | - | no | - |
Composition
| SUPPORT | EPDM-based synthetic rubber |
|---|---|
| elastic polyurethane foam with additives |
Specifications
CONNECT BAND
Supply and installation of sealing wall barrier for irregular substrates, Type CONNECT BAND.
Properties
-
Water vapour transmission (Sd)[m]: 55
-
Tensile strength [MPa]: ≥ 6,5
-
Elongation [%]:≥ 300
-
Resistance to nail tearing [kN/m2]:≥ 25
-
Watertightness (24h): comply with (EN 1928)
-
Reaction to fire: class E (EN 13501-1)
-
Resistance to temperature [C°]: -30/+100
-
Application temperature [C°]: +5/+35
-
Storage temperature [C°]: +1/+25
-
Resistance to UV and ozone: permanent
-
French VOC classification: A+
-
VOC emissions: very low
-
Solvents: no
Description
The application surface must be dry, free of dust and grease, and not be anti-adhesive. Surface elements must be removed so that the membrane is not damaged during application.
Recommended use
It protects timber from rising damp and ensures excellent airtightness.
Adhesive PU foam profiles make it possible to compensate for any irregularities in the foundation.
Extremely thermostable and flexible even at low temperatures. Compatible with bitumen and major building materials.
Installation
If an adhesive tape is used, remove the first half of the liner and apply it along the length of the element.
