METAL HANGERS WITH INTERNAL WINGS

BSI

Standardized, certified, fast and inexpensive system.

Suitable for the fastening of joints in mixed mode bending.

Thanks to the internal wings, the junction is almost entirely “concealed”.

Technical data sheets	Choose a Language
ETA Certificate	Choose a Language
Declaration of performance (DOP)	Download
Item specification	Choose a Language
File CAD	Choose a Language

CODE	B [mm]	H [mm]	s [mm]	pcs.
BSIS40110	40	110	2	50
BSIS60100	60	100	2	50
BSIS60160	60	160	2	50
BSIS70125	70	125	2	50
BSIS80120	80	120	2	50
BSIS80150	80	150	2	50
BSIS80180	80	180	2	25
BSIS90145	90	145	2	50
BSIS10090	100	90	2	50
BSIS100120	100	120	2	50
BSIS100140	100	140	2	50
BSIS100170	100	170	2	50
BSIS100200	100	200	2	25
BSIS120120	120	120	2	25
BSIS120160	120	160	2	25
BSIS120190	120	190	2	25
BSIS140140	140	140	2	25
BSIS140180	140	180	2	25

CODE	B [mm]	H [mm]	s [mm]	pcs.
BSIG120240	120	240	2.5	20
BSIG140240	140	240	2.5	20
BSIG160160	160	160	2.5	15
BSIG160200	160	200	2.5	15
BSIG180220	180	220	2.5	10
BSIG200200	200	200	2.5	10
BSIG200240	200	240	2.5	10

Supply and installation of metal hanger with internal wings for timber structures, Type BSI.
CE marking in accordance with ETA

Field of use:

Material:

Geometry:

– B (mm) = :
– H (mm) = :

Indications for installation and mechanical performance as reported in the product data sheets and provided by the technical drawings of the project.
