PAN HEAD SCREW
HBS PLATE EVO
The HBS PLATE EVO wood screw is designed for outdoor steel-to-timber joints.
The special coating makes it perfect for applications in service class 3 or with aggressive or chemically treated woods.
HBS PLATE EVO, the wood screw for fastening metal plates that is not sensitive to aggressive environments.
HBS PLATE EVO is the wood screw designed for fastening metal plates to timber in outdoor environments.
Its truncated cone-shaped head and greater thickness enable secure fastening of plates to timber. The small sizes (5,0 and 6,0 mm) are also suitable for timber-to-timber joints. HBS PLATE EVO is perfect for fastening Rothoblaas standard plates in outdoor environments. The 5 mm diameter version is also suitable for fastening patio deck planks.
The special 20 μm multilayer C4 EVO coating with a surface treatment of epoxy resin and aluminium flakes showed no rust after 1440 hours of salt spray exposure testing, according to ISO 9227.
Made of carbon steel, with a coating that is highly resistant to corrosion, it can be used in service class 3 outdoor applications and under class C4 atmospheric corrosion conditions.
HBS PLATE EVO is ideal for use with wood-based panels, solid timber, glulam, CLT, LVL, and high-density and aggressive woods. Service classes 1, 2 and 3.
Features
FOCUS | corrosiveness class C4 |
---|---|
HEAD | shoulder for plate |
DIAMETER | from 5,0 mm to 10,0 mm |
LENGTH | from 40 mm to 180 mm |
Documents
Technical data sheets | |
---|---|
Minimum Distances Guide | |
Technical data sheets USA 🇺🇸 | |
ICC-ES Evaluation report USA | |
ICC-ES Listing report CANADA | |
ETA Certificate | |
Declaration of performance (DOP) | Download |
File CAD HBS P 2022 | |
File BIM.ifc | |
File BIM.rfa | |
Technical data sheets HBS P EVO 2022 |
Installation manual
Installation Instructions |
---|
HBS P EVO Ø5 - Ø6
CODE | info | d₁
[mm]
|
L
[mm]
|
b
[mm]
|
d₁
[in]
|
L
[in]
|
b
[in]
|
TX | pcs. |
---|---|---|---|---|---|---|---|---|---|
HBSPEVO550 | - | 5 | 50 | 30 | 0.2 | 1 15/16'' | 1 3/16'' | TX25 | 200 |
HBSPEVO560 | - | 5 | 60 | 35 | 0.2 | 2 3/8'' | 1 3/8'' | TX25 | 200 |
HBSPEVO570 | - | 5 | 70 | 40 | 0.2 | 2 3/4'' | 1 9/16'' | TX25 | 100 |
HBSPEVO580 | - | 5 | 80 | 50 | 0.2 | 3 1/8'' | 1 15/16'' | TX25 | 100 |
HBSPEVO680 | - | 6 | 80 | 50 | 0.24 | 3 1/8'' | 1 15/16'' | TX30 | 100 |
HBSPEVO690 | - | 6 | 90 | 55 | 0.24 | 3 1/2'' | 2 3/16'' | TX30 | 100 |
HBS PL EVO Ø8 - Ø10 - Ø12
CODE | info | d₁
[mm]
|
L
[mm]
|
b
[mm]
|
d₁
[in]
|
L
[in]
|
b
[in]
|
TX | pcs. |
---|---|---|---|---|---|---|---|---|---|
HBSPLEVO840 | - | 8 | 40 | 32 | 0.32 | 1 9/16'' | 1 1/4'' | TX40 | 100 |
HBSPLEVO860 | - | 8 | 60 | 52 | 0.32 | 2 3/8'' | 2 1/16'' | TX40 | 100 |
HBSPLEVO880 | - | 8 | 80 | 55 | 0.32 | 3 1/8'' | 2 3/16'' | TX40 | 100 |
HBSPLEVO8100 | - | 8 | 100 | 75 | 0.32 | 4'' | 2 15/16'' | TX40 | 100 |
HBSPLEVO8120 | - | 8 | 120 | 95 | 0.32 | 4 3/4'' | 3 3/4'' | TX40 | 100 |
HBSPLEVO8140 | - | 8 | 140 | 110 | 0.32 | 5 1/2'' | 4 3/8'' | TX40 | 100 |
HBSPLEVO8160 | - | 8 | 160 | 130 | 0.32 | 6 1/4'' | 5 1/8'' | TX40 | 100 |
HBSPLEVO1060 | - | 10 | 60 | 52 | 0.4 | 2 3/8'' | 2 1/16'' | TX40 | 50 |
HBSPLEVO1080 | - | 10 | 80 | 60 | 0.4 | 3 1/8'' | 2 3/8'' | TX40 | 50 |
HBSPLEVO10100 | - | 10 | 100 | 75 | 0.4 | 4'' | 2 15/16'' | TX40 | 50 |
HBSPLEVO10120 | - | 10 | 120 | 95 | 0.4 | 4 3/4'' | 3 3/4'' | TX40 | 50 |
HBSPLEVO10140 | - | 10 | 140 | 110 | 0.4 | 5 1/2'' | 4 3/8'' | TX40 | 50 |
HBSPLEVO10160 | - | 10 | 160 | 130 | 0.4 | 6 1/4'' | 5 1/8'' | TX40 | 50 |
HBSPLEVO10180 | - | 10 | 180 | 150 | 0.4 | 7 1/8'' | 6'' | TX40 | 50 |
HBSPLEVO12120 | - | 12 | 120 | 90 | 0.48 | 4 3/4'' | 3 1/2'' | TX50 | 25 |
HBSPLEVO12140 | - | 12 | 140 | 110 | 0.48 | 5 1/2'' | 4 3/8'' | TX50 | 25 |
HBSPLEVO12160 | - | 12 | 160 | 120 | 0.48 | 6 1/4'' | 4 3/4'' | TX50 | 25 |
HBSPLEVO12180 | - | 12 | 180 | 140 | 0.48 | 7 1/8'' | 5 1/2'' | TX50 | 25 |
HBSPLEVO12200 | - | 12 | 200 | 160 | 0.48 | 8'' | 6 1/4'' | TX50 | 25 |
HBS P EVO Ø8 - Ø10
CODE | info | d₁
[mm]
|
L
[mm]
|
b
[mm]
|
d₁
[in]
|
L
[in]
|
b
[in]
|
TX | pcs. |
---|---|---|---|---|---|---|---|---|---|
HBSPEVO840 | - | 8 | 40 | 32 | 0.32 | 1 9/16'' | 1 1/4'' | TX40 | 100 |
HBSPEVO860 | - | 8 | 60 | 52 | 0.32 | 2 3/8'' | 2 1/16'' | TX40 | 100 |
HBSPEVO880 | - | 8 | 80 | 55 | 0.32 | 3 1/8'' | 2 3/16'' | TX40 | 100 |
HBSPEVO8100 | - | 8 | 100 | 75 | 0.32 | 4'' | 2 15/16'' | TX40 | 100 |
HBSPEVO8120 | - | 8 | 120 | 95 | 0.32 | 4 3/4'' | 3 3/4'' | TX40 | 100 |
HBSPEVO8140 | - | 8 | 140 | 110 | 0.32 | 5 1/2'' | 4 3/8'' | TX40 | 100 |
HBSPEVO8160 | - | 8 | 160 | 130 | 0.32 | 6 1/4'' | 5 1/8'' | TX40 | 100 |
HBSPEVO1060 | - | 10 | 60 | 52 | 0.4 | 2 3/8'' | 2 1/16'' | TX40 | 50 |
HBSPEVO1080 | - | 10 | 80 | 60 | 0.4 | 3 1/8'' | 2 3/8'' | TX40 | 50 |
HBSPEVO10100 | - | 10 | 100 | 75 | 0.4 | 4'' | 2 15/16'' | TX40 | 50 |
HBSPEVO10120 | - | 10 | 120 | 95 | 0.4 | 4 3/4'' | 3 3/4'' | TX40 | 50 |
HBSPEVO10140 | - | 10 | 140 | 110 | 0.4 | 5 1/2'' | 4 3/8'' | TX40 | 50 |
HBSPEVO10160 | - | 10 | 160 | 130 | 0.4 | 6 1/4'' | 5 1/8'' | TX40 | 50 |
HBSPEVO10180 | - | 10 | 180 | 150 | 0.4 | 7 1/8'' | 6'' | TX40 | 50 |
