  5. TYP FD

DOUBLE FIXED POST BASES

TYP FD

Documents

Technical data sheets
Declaration of performance (DOP) Download
ETA Certificate
Item specification
File CAD

FD10

CODE B
[mm]
P
[mm]
H
[mm]
s
[mm]
pcs.
FD10120 121 56 200 2.5 1
FD10140 141 66 200 2.5 1
FD10160 161 76 200 2.5 1
FD10180 181 86 200 2.5 1
FD10200 201 96 200 2.5 1

FD70

CODE B
[mm]
P
[mm]
H
[mm]
s
[mm]
pcs.
FD7080 81 81 180 3 1
FD70100 101 101 220 3 1

FD20

CODE B
[mm]
P
[mm]
H
[mm]
s
[mm]
pcs.
FD20120 121 38 200 4 1
FD20140 141 46 200 4 1
FD20160 161 54 200 4 1
FD20200 201 66 200 4 1

FDI20 A2 | AISI304

CODE B
[mm]
P
[mm]
H
[mm]
s
[mm]
pcs.
FDI20100 100 30 230 3 1
FDI20120 120 40 250 3 1
FDI20140 140 40 250 3 1
FDI20160 160 40 280 3 1
FDI20200 200 50 300 3 1

FD30

CODE B
[mm]
H
[mm]
s
[mm]
pcs.
FD3060 60 180 4 1
FD3080 80 240 4 1

FD50

CODE B
[mm]
H
[mm]
s
[mm]
pcs.
FD5050 46 185 4 1
FD5080 76 220 4 1

FD60

CODE B
[mm]
H
[mm]
s
[mm]
pcs.
FD6050 46 185 4 1
FD6080 76 220 4 1
